Hexagonal architecture and Python - Part IV: Lightweight integration tests

Intro

It is very easy to unit test the components of an application that follows Hexagonal architecture principles. The components belong to certain layers, and it's quite straightforward to mock the following dependency layer. However, the problem with such an approach is that we never test the application as a whole, and have to rely on expensive integration or end-to-end tests to do so.

We can test the application components in sociable manner, leaving our components' direct dependencies as-is, and pushing the mocks further to the application edges.

If we push the mocks too far, we end up with lightweight integration tests. Let's explore how we can utilise such tests in a context of Django application and what benefits we can reap.

The original article focused on such "lightweight integration" tests. I even dared to call them "sociable"! Jarkko "jmp" Piiroinen was very generous to thoroughly review the article. He pointed that sociable tests, rather implies testing a thing within the application core (or "Application" in Alistair Cockburn's definition) with its neighbours/collaborators. Testing the whole flow by mocking the rightmost calls is "sociable tests pushed too far", or as Jarkko put it "rather lightweight end-to-end tests".

The updated article is about exploring the ways to conduct such tests in a Django application setup, focusing on the benefits and caveats.

Time flies (darn, I say that again)! I wrote the original "Hexagonal Architecture and Python" series back in 2022, which was only three years ago (honestly, it feels like yesterday!) Since then my understanding of RESTful API design and Domain-Driven Design has deepened. But the biggest shift, however, has occurred in where I start and how I test.

I used to believed that the implementation of the domain model should precede exposing any API. I still design the domain model first before deriving API structure from if. However, I implement barebones API first, initially hard-coding and short-circuiting domain logic, to enable early integrations and feedback. This approach helps steer the development in the right direction, keeps API consumers happy and avoids "big bang" release surprises.

This led to the second change. I used to TDD every layer and every component of the application independently. Today, I aim at unit testing the interconnected parts of the system.

Bear in mind, that the system users often don't care about what's happening under its hood. They are more concerned with the system's public contract - its behaviour when queried and commanded through the public interfaces. System developers, on the other hand, also need assurance that the system interacts with its downstream dependencies as expected. We can apply behavior testing similarly: by testing the system via its public interfaces and downstream interactions, we reduce the need to test the application layers in isolation.

Just so we're clear, I'm not calling anyone to put the whole thing together and test it on the launch pad. That's a recipe for disaster - remember what happened to the Soviet N1 Moon rocket?

Adverse characteristics of the large cluster of thirty engines and its complex fuel and oxidizer feeder systems were not revealed earlier in development because static test firings had not been conducted. (Wikipedia)

Instead, I'm looking for relatively lightweight ways to test the entire system, without going for a full end-to-end setup.

Hexagonal architecture - as described in the articles series

Let's recall the application and its architecture as described in the articles series:

The Application has a layered structure: the Core, which includes Domain models and services; The driving/in/API (application programming interface) and driven/out/SPI (service provider interface) ports for incoming and outgoing interactions; and API and SPI adapters.

Python wise:

• The Domain model consists of classes and methods which reflect the real world domain rules. They are "pure" in nature, because they don't have any outer world dependencies.
• We can think of API and SPI ports as delegates - basically, function signatures. We can use Python Protocols or Abstract Base Classes to define them in OOP-compatible way.
• The Application Services implement API ports and orchestrate the flow between domain models and SPI ports. They invoke SPI ports and can also invoke other API ports when necessary.
• The SPI adapters implement SPI ports. SPI adapters are the bridges between the application and downstream dependencies (databases, cashes, message queues, file systems, other services etc.)
• The API adapters connect the outer world to the application. They receive commands and queries through different channels (command line, http, RPC, message queue etc.) and invoke API ports. The same API port can be invoked by many adapters - think of making the same query via a command line, or via a RESTful HTTP interface.

Testing the application

Martin Fowler speaks of "Solitary" and "Sociable" tests in the renowned article "Unit Test". Solitary tests mock the direct dependencies of the component under test. This is how I originally implemented tests in the "Hexagonal Architecture with Django" project. Tests like these run blazingly fast, but they only test the isolated behaviour of a given component (like an HTTP controller, an application service, or a database entities mapper) with fake downstream layer interactions.

Defining sociable tests is trickier:

When xunit testing began in the 90's we made no attempt to go solitary unless communicating with the collaborators was awkward (such as a remote credit card verification system).

I think that the term “unit testing” is appropriate because these tests are tests of the behavior of a single unit. We write the tests assuming everything other than that unit is working correctly.

—Martin Fowler, "Unit Test".

So, in my perspective a unit test is sociable when it verifies a unit of behaviour across multiple components boundaries. In the verified interaction, at least one direct dependency is not mocked, however the further dependencies can be mocked.

Finally, we utilise higher-level integration or end-to-end tests to verify the behaviour flow throughout the application and its dependencies. Nowadays, tools such as Testcontainers allow the isolation of these tests by spinning up the real databases, caches and other dependencies for a short test lifetime. However, this setup might be too resource-intensive, or other downstream dependencies, that cannot be dockerised may need to come into play. This leaves us with slow and fragile classical e2e tests in an integration environment.

What if we push sociable tests a bit further? We can mock the layer which stands between our adapters and external dependencies. This ensures that an API test flow passes forward and back through the whole application in a deterministic and isolated environment:

Architecture revised

Software architecture is important because it allows us to independently evolve different parts of the application and delay decisions. In a way, architecture constrains us, but helps keep the system organised.

My presentation of Hexagonal Architecture in this series of articles, especially the testing part, was a bit bloated. Alistair Cockburn said nothing about the application's (core) internals. It's up to us whether we introduce "Service", "Domain" or any other layer or concept. Just think: if an HTTP adapter handles a GET request to return raw data from a single table in the database, why even bother with "Service" and "Domain" layers which would only perform data transformations?

So, when it comes to lightweight integration testing, we leave the application core as a black box, and interact with adapters only.

Lightweight integration tests -driven development

A classical end-to-end test is a poor development driver. It takes minutes, sometimes tens of minutes to run, often breaks, has a complicated setup, and ... (your favourite fallacies here). A lightweight integration test is somewhat better: it's fast and fully under our control. However, it rather drives adapters development, NOT the application core development. It also requires a complicates setup, especially when it comes to test doubles.

Nevertheless, let's explore how such a test drives implementation. What steps would we take?

1. Pick a behaviour unit.
2. Write a test for its API, asserting only the response.
3. Write a minimal implementation to pass the test.
4. If the behaviour is not pure and hits downstream dependencies, write a test similar to (2), but this time verify the dependency interaction. Mock the dependencies and verify interactions via these mocks.
5. Write a minimal implementation to pass the test.
6. If any other tests break, fix them. Here, you enter a recursion, starting at step 1 with a broken behaviour unit.
7. Refactor. Remove duplication in application and tests code. Apply Clean/Hexagonal architecture principles when necessary.

Let's walk through these steps by implementing the original "Vote for an article" use case from scratch. I will not include implementation code here, just the tests code. That's because the implementation stays the same, but the tests are quite different.

Use case: Vote for an article

Let's recap the requirements for this use case:

1. Every article has a rating.
2. Users can change an article's rating by either "upvoting" or "downvoting" it.
3. To vote on an article, a user's karma (their user rating) needs to be higher than 5
4. A user can only vote on each article once.

This translates into the following user story:

1
2
3
4

Given A registered user
      who can vote on articles.
When they vote on an article.
Then the article's rating changes to reflect their vote.

1
2
3
4
5

### TODO

* [ ] Test that "When user successfully votes for an article,
      the system responds with HTTP CREATED status and the vote details".
* [ ] Implement the view which handles voting for articles.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13

def test_when_user__successfully_votes_for_existing_article__system_returns_http_created_with_vote_details():
    response = post_article_vote(
        article_id='3f577757-0000-0000-0000-000000000000',
        user_id='9af8961e-0000-0000-0000-000000000000',
        vote='DOWN'
    )

    assert response.status_code == HTTPStatus.CREATED
    assert response.data == {
        'article_id': '3f577757-0000-0000-0000-000000000000',
        'user_id': '9af8961e-0000-0000-0000-000000000000',
        'vote': 'DOWN'
    }

1
2
3
4
5
6
7
8

### TODO

* [ ] Test that "When user successfully votes for an article,
      the system persists the vote"
* [ ] Implement persisting the vote.
* [X] Test that "When user successfully votes for an article,
      the system responds with HTTP CREATED status and the vote details".
* [X] Implement the view which handles voting for articles

1
2
3
4
5
6

@pytest.fixture
def mock_persisting_article_vote():
    with patch.object(ArticleVoteEntity, 'save', autospec=True) as mock:
        def _mock_persisting_article_vote():
            return mock
    yield _mock_persisting_article_vote

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17

def test_when_user__successfully_votes_for_existing_article__system_persists_the_vote_in_the_database(
    mock_persisting_article_vote,
    post_article_vote
):
    spy = mock_persisting_article_vote()

    post_article_vote(
        article_id='3f577757-0000-0000-0000-000000000000',
        user_id='9af8961e-0000-0000-0000-000000000000',
        vote='down'
    )

    # use the captured ``self`` value from ArticleVoteEntity().save()
    entity = spy.call_args[0][0]
    assert entity.article_id == UUID('3f577757-0000-0000-0000-000000000000')
    assert entity.user_id == UUID('9af8961e-0000-0000-0000-000000000000')
    assert entity.vote == 'down'

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

def test_when_user__successfully_votes_for_existing_article__system_persists_the_vote_in_the_database(...):
    ...
    entity = spy.saved_article_voted_entity
    assert entity.vote == 'down'
    ...


class SaveArticleVoteEntitySpy:
    saved_article_voted_entity: Optional[ArticleVoteEntity] = None

    def save_article_vote_entity_mock(self, entity, *_args, **_kwargs):
        self.saved_article_voted_entity = entity


@pytest.fixture
def mock_persisting_article_vote():
    spy = SaveArticleVoteEntitySpy()

    with patch.object(ArticleVoteEntity, 'save', autospec=True) as save_mock:
        def _mock_persisting_article_vote() -> SaveArticleVoteEntitySpy:
            save_mock.side_effect = spy.save_article_vote_entity_mock
            return spy
        yield _mock_persisting_article_vote

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38

class TestWhenUserSuccessfullyVotesForExistingArticle:
    @pytest.fixture(autouse=True)
    def arrange(
        self,
        given_a_user_who_can_vote,
        given_no_existing_article_votes,
        mock_persisting_article_vote,
        post_article_vote
    ):
        given_a_user_who_can_vote(
            UUID('9af8961e-0000-0000-0000-000000000000')
        )
        given_no_existing_article_votes()
        self.persisting_article_vote_spy = mock_persisting_article_vote()
        self.post_article_vote = post_article_vote

    def act(self) -> Response:
        return self.post_article_vote(
            article_id='3f577757-0000-0000-0000-000000000000',
            user_id='9af8961e-0000-0000-0000-000000000000',
            vote='down'
        )

    def test_system_returns_http_created_with_vote_details(self):
        response = self.act()
        assert response.status_code == HTTPStatus.CREATED
        assert response.data == {
            'article_id': '3f577757-0000-0000-0000-000000000000',
            'user_id': '9af8961e-0000-0000-0000-000000000000',
            'vote': 'DOWN'
        }

    def test_system_persists_the_vote_in_the_database(self):
        self.act()
        entity = self.persisting_article_vote_spy.saved_article_voted_entity
        assert entity.article_id == UUID('3f577757-0000-0000-0000-000000000000')
        assert entity.user_id == UUID('9af8961e-0000-0000-0000-000000000000')
        assert entity.vote == 'down'

Use case: Only existing user can vote for an article

1
2
3

### TODO

* [ ] Test that only existing user can vote for an article.

1
2
3
4

### TODO

* [ ] **Test that a non-existing user can't vote for an article.**
* [ ] Test that only an existing user can vote for an article.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16

def test_when_voting__as_non_existing_user__system_returns_http_not_found_with_error_details(
    given_no_existing_users,
    post_article_vote
):
    given_no_existing_users()

    response = post_article_vote(
        user_id='a3853333-0000-0000-0000-000000000000'
    )

    assert response.status_code == HTTPStatus.NOT_FOUND
    assert response.data == {
        'detail': "User 'a3853333-0000-0000-0000-000000000000' not found",
        'status': 404,
        'title': 'Error'
    }

1
2
3

class VotingUserEntityEmptyObjectManagerMock:
    def get(self, *_args, **_kwargs) -> VotingUserEntity:
        raise VotingUserEntity.DoesNotExist()

1
2
3
4
5
6
7
8
9

@pytest.fixture
def given_no_existing_users():
    original_voting_user_entity_manager = VotingUserEntity.objects

    def _given_no_existing_user():
        VotingUserEntity.objects = VotingUserEntityObjectManagerMock()
    yield _given_no_existing_user

    VotingUserEntity.objects = original_voting_user_entity_manager

1
2
3

Unexpected error occurred: Database access not allowed,
use the "django_db" mark, or the "db" or "transactional_db" fixtures
to enable it.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

class VotingUserEntityObjectManagerMock:
    stub: VotingUserEntity | None = None

    def __init__(self, stub: VotingUserEntity):
        super().__init__()
        self.stub = stub

    def get(self, *_args, **_kwargs) -> VotingUserEntity:
        if self.stub is None:
            raise VotingUserEntity.DoesNotExist()
        return self.stub

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17

@pytest.fixture
def given_voting_user():
    original_voting_user_entity_manager = VotingUserEntity.objects

    def _given_voting_user(
        user_id: UUID = uuid4(),
        karma: int = 10
    ):
        VotingUserEntity.objects = VotingUserEntityObjectManagerMock(
            VotingUserEntity(
                user_id=user_id,
                karma=karma
            )
        )
    yield _given_voting_user

    VotingUserEntity.objects = original_voting_user_entity_manager

The price to pay

The lightweight integration tests let us quickly test application as a whole, using mocks only at the system edges. However, these mocks can become quite sophisticated because a single use case triggered at the API often results in many downstream interactions. For example, imagine a scenario where the application returns HTTP 409 - Conflict, when someone votes for an article a second time. We'll need to mock User.objects (a Django DB model ObjectManager) to provide an existing user, as well as provide an existing article via a mocked Article.objects manager.

At some point, the mocks can become too sophisticated and create a mess of their own. That's when real integration testing alternatives like in-memory SQLite, or even Testcontainers start making more sense. We may loose the rapid feedback of unit tests, but save ourselves a lot of time spent on maintenance of messy test doubles.

Conclusion

Solitary unit tests are excellent for developing individual components in isolation. Sociable unit tests are a classical approach to testing pieces together, mocking the complicated dependencies, for example, those which cross the I/O boundary. Both solitary and sociable unit tests are my tools of choice for test-driven development.

Lightweight integration tests ensures that all components work together correctly as a complete application, while preserving the speed and flexibility of unit tests. However, we need to invest significantly in edge mocks to emulate rightmost interactions. Moreover, these tests primarily drive the implementation of application edges - the adapters.

Lightweight integration tests are a good alternative to either missing integration tests or integration tests which require an equally complicated setup. They can be quite useful when refactoring a legacy system, that doesn't have any tests. We can capture the interaction on the edges and ensure that it doesn't change during development.

Acknowledgements

Once again, Jarkko "jmp" Piiroinen nudged me to dive deeper and challenge my own understanding of the subject. I'm very grateful for your input, Jarkko!
